Woods Hole Oceanographic Institution
Cruise Planning Synopsis
KN214 | |
Ship | |
R/V Knorr | |
Cruise Party | |
Paul Matthias: Principal Investigator Organization Name USA +1 508 289 3672 pmatthias@whoi.edu Albert Plueddemann: Chief Scientist Woods Hole Oceanographic Institution Clark 202A, MS#29 Woods Hole, Ma. USA 02543 +1 508 289 2789 aplueddemann@whoi.edu |
Departure: Nov 22, 2013 | |
Woods Hole | |
Arrival: Dec 5, 2013 | |
Woods Hole | |
Operations Area | |
Continental shelf and slope south of New England | |
Lat/Lon: 40° 0.0′ N / 71° 0.0′ W | |
Depth Range: 90 / 500 | |
Will the vessel be operating within 200 NM of a foreign country? | no |
Science Objectives | |
This cruise represents the initial infrastructure deployment for the Pioneer Array of the National Science Foundation’s Ocean Observatories Initiative (OOI). The Pioneer Array will include a network of moorings and autonomous robotic vehicles to monitor waters of the continental shelf and slope south of New England and, in particular, the shelfbreak front where nutrients and other properties are exchanged between the coast and the deep ocean. Data from the Pioneer Array will provide new insights into coastal ocean processes such as shelf/slope nutrient exchange, air-sea property exchange, carbon cycling, and ocean acidification that are important to the New England shelf, and to continental shelf ecosystems around the world. For further information, see http://www.oceanobservatories.org. | |
Science Activities | |
The Pioneer Phase I cruise (Pioneer I) has 4 main objectives and 3 ancillary objectives. The main objectives are: 1) Deploy an OOI Coastal Surface Mooring (CSM) and validate its operation, 2) Deploy 2 OOI Coastal Profiler Moorings (CPMs) and validate their operation, 3) Perform field verification activities, including a meteorological intercomparison at the CSM site and CTD casts with water sampling at mooring sites. The ancillary objectives are a) Seabeam surveys of the mooring sites and of the Pioneer moored array region in general, b) Cross-shelf and along-shelf surveys in the vicinity of the moored array using the shipboard ADCPs. | |
Additional Info | |
Pre-cruise Planning Meeting: Visit WHOI | |
Stations: | |
Pioneer Central Site Distance: 85 Days: 2 Latitude: 40° 8.2 N Longitude: 70° 46.5 E | |
Supporting documentation: | |
»Pioneer_Planned_Installation_Schedule_2013-11-09_ver_1-21.docx | |
»Pioneer_I_PATON_Submission_2013-11-8-V1.pdf | |
»NAE-2010-1283_OOI_Pioneer_Array_Permit-1.pdf | |
»LNM_mooring_predeploy_Pioneer1-2.txt | |
»OOI_Pioneer_1_Projected_Deckload.xls | |
»Pioneer_1_RV_KNORR__DECK_LAY_OUT_vers.3_111213-1.pdf | |
»Pioneer_1_Moorings_to_be_deployed-1.pdf | |
»personnel_list_Knorr_214.docx | |
»Knorr_science_berthing.pdf | |
»Pioneer_2013_station_list.xls | |
»Pioneer_micrositing3_distances_km.png |
Funding |
Funding Agency: NSF | |
Grant or contract number: 000000 |
Scientific Instrumentation for R/V Knorr |
Shipboard Equipment | |||||||||||
Bathymetry System 12 kHz | |||||||||||
ADCP 300 kHz | |||||||||||
ADCP 75 kHz | |||||||||||
Multibeam | |||||||||||
Shipboard Communication | |||||||||||
Basic Internet access via HiSeasNet | |||||||||||
CTD/Water Sampling | |||||||||||
Wet Labs C*Star transmissometer (660nm wavelength) | |||||||||||
SBE43 oxygen sensor | |||||||||||
911+ Rosette 24-position, 10-liter bottle Rosette with dual T/C sensors | |||||||||||
Biospherical underwater PAR (1000m depth limit) with reference Surface PAR | |||||||||||
Wet Labs FLNTURTD Combination Flourometer and Turbidity Sensor | |||||||||||
Critical CTD Sensors | |||||||||||
Hydrographic Analysis Equipment | |||||||||||
Oxygen Sample Bottles (available in 150 ml sizes) | |||||||||||
Salinometer | |||||||||||
Dissolved Oxygen Titration System (Brinkmann Titrator) | |||||||||||
Salt Bottles (2 cases of 125 ml provided) | |||||||||||
MET Sensors | |||||||||||
Barometric Pressure | |||||||||||
Air temperature | |||||||||||
Precipitation | |||||||||||
Relative Humidity | |||||||||||
Wind speed and direction | |||||||||||
Short Wave Solar Radiation | |||||||||||
Sample Storage | |||||||||||
Freezer -70°C 3.2 cu. ft. ea. | |||||||||||
Storage Notes: Freezer for chlorophyll and nutrient samples | |||||||||||
Navigation | |||||||||||
Will you be using Long Base Line (LBL) navigation? | no | ||||||||||
How many nets? | null | ||||||||||
How many tansponders? | null | ||||||||||
Will you be using Doppler/GPS navigation? | no | ||||||||||
Navigation | |||||||||||
GPS | |||||||||||
Navigation Notes: | |||||||||||
Winches | |||||||||||
Other Portable Winch | |||||||||||
Mooring / TSE winch | |||||||||||
Trawl Winch with 9/16th trawl wire | |||||||||||
CTD Winch with .322" Electro-mechanical wire | |||||||||||
Hydro Winch with .25" hydro wire | |||||||||||
Winch Notes:
TSE from sourced from WHOI Rigging Shop Power Requirements:
| |||||||||||
Wire use and application | |||||||||||
Hydro Winch with .25" hydro wire | |||||||||||
CTD Winch with .322" Electro-mechanical wire | |||||||||||
Trawl Winch with 9/16th trawl wire | |||||||||||
Wire Notes: CTD winch for 24 bottle rosette, Hydro winch for release/linepack tests, trawl winch for anchor lowering. | |||||||||||
Standard Oceanographic Cables | |||||||||||
|
Science Van 1 | |||
Type/size: 20' rigging van | Location: main deck | ||
Water: no | Power:440 3-phase |
Specialized Deck Equipment
Mooring Deployment/Recovery Equipment Required: yes | Type: heavy lift winch, TSE Winch |
Cruise Specific Science Winch Required: no | Type: |
Nets Required: no | Type: |
Over the Side Equipment
Winches as above, blocks for A-Frame
Special Requirements
Elecrical Power: yes | Identify: 100 AMP |
Equipment Handling: no | Identify: |
Inter/intraship Communications: no | Identify: |
Science Stowage: no | Identify: |
Water: no | Identify: |
Additional Cruise Items/Activities
Hazardous Material
Radioactive Material
Additional Information
ADCP, Seabeam, CTD
Checklist & Notes |
Checklist | |
U.S. Customs Form: | no |
Diplomatic Clearance: | no |
Date Submitted: | |
Date Approved: | |
Agent Information: | |
Countries: | |
Notes: | |
Isotope Use Approval: | no |
Isotope Notes: | |
SCUBA Diving: | no |
Checklist | |
SSSG Tech: | |
