Woods Hole Oceanographic Institution

Cruise Planning Questionnaire

The Next 'OSNAP'

Ship

RV Neil Armstrong

Vehicles


Cruise Party

Robert Pickart: Chief Scientist, Principal Investigator
Woods Hole Oceanographic Institution Clark 359B, MS#21 Woods Hole, Ma. USA 02543
+1 508 289 2858
rpickart@whoi.edu

Fiamma Straneo: Principal Investigator
Woods Hole Oceanographic Institution Clark 339, MS#21 Woods Hole, Ma. USA 02543
+1 508 289 2914
fstraneo@whoi.edu


Departure: Woods Hole, MA on Jun 23, 2020

Arrival: Woods Hole, MA on Aug 1, 2020

Mobilization Date: Jun 19, 2020

Demobilization Date: Aug 2, 2020

Supporting documentation:

»OSNAP_Straneo_CF_to_be_deployed_2020.pdf
»OSNAP_Pickart_To_be_Deployed_2020.pdf
»2018_OSNAP_mooring_deployments_report_table.xlsx
»OSNAP_Pickart_As_Deployed_2018.pdf
»OSNAP_Straneo_As_Deployed_2018.pdf

Operations Area: Southern Greenland


Lat/Lon: 59° 20.0′ N / 43° 50.0′ W

Depth Range: 100 / 3500

Will the vessel be operating within 200 NM of a foreign country? Greenland
Are visas or special travel documents required? no

Science objectives

This research is part of the Overturning in the Subpolar North Atlantic Program (OSNAP), an effort to determine the strength of the meridional overturning circulation and associated heat and freshwater fluxes in the subpolar North Atlantic. It is a collaborative program with scientists from several nations, including the U.K., the Netherlands, Germany, France, Canada and China.

The specific objectives of this cruise are as follows:

1. To service 17 current meter moorings in the southeast Labrador Sea and southwest Irminger Sea.
2. To conduct a hydrographic/velocity survey in the vicinity of Cape Farewell.


Science Activities

1. We will attempt to recover and re-deploy 17 moorings. There are two types of moorings: tall oceanographic moorings (9); shelf-tripods (8). Since the time at the study is reduced (due to the COVID-19 situation), it is likely that we won't be able to service all of the moorings.

2. We will occupy CTD stations at all of the mooring sites, and also occupy some additional sections as time permits.

3. We will collect underway data throughout the cruise (vessel-mounted ADCP, Knudsen, met sensors).


Pre-cruise planning meeting: Teleconference

Teleconference is necessary due to COVID-19

Stations:


Funding Agency: NSF #OCE-1756361


- added NSF #OCE-1756361 on May 23, 2020 5:25 PM by
<Could not load the preview of Funding data >

R/V Armstrong

Shipboard Equipment

12 kHz Pinger for Wire Use
A-Frame
ADCP 150 kHz
ADCP 300 kHz
ADCP 38 kHz
Bathymetry System 12 kHz
Bathymetry System 3.5 kHz
Crane
Dynamic Positioning System
EK80 Sonar
EM122 (12 kHz) Multibeam Echosounder
EM710 MkII (40 to 100 kHz) Multibeam Echosounder
K-Synch System
Plotters
Science Underway Seawater System


Shipboard Equipment Notes:

Shipboard Communication

Basic Internet access via HiSeasNet
Is there a need to receive data from shore on a regular basis?
Is there a need to transfer data to shore on a regular basis?


Shipboard Communication Notes: We need to transfer ADCP data to/from the ship for review by Jules Hummon at UH.

CTD/Water Sampling

911+ Rosette 24-position, 10-liter bottle Rosette with dual T/C sensors
SBE43 oxygen sensor
Wet Labs C*Star transmissometer (660nm wavelength)
Biospherical underwater PAR (1000m depth limit) with reference Surface PAR
Seapoint STM turbidity sensor
Wet Labs ECO-AFL fluorometer
Wet Labs FLNTURTD Combination Flourometer and Turbidity Sensor

Critical CTD Sensors:  Two optode sensors on package (one integrated with the CTD). Complete backup CTD system needed.

Hydrographic Analysis Equipment

Salinometer
Salt Bottles (2 cases of 125 ml provided)

MET Sensors

Air temperature
Barometric Pressure
Precipitation
Relative Humidity
Short Wave Solar Radiation
Wind speed and direction
Long Wave Solar Radiation

Sample Storage

Scientific Walk-in Freezer


Storage Notes: We will bring a spare CTD system (Marshall Swartz is taking care of this)

We will bring oxygen sample bottles.

We will use the science walk-in freezer for storing ADCPs and MicroCAT boxes

Navigation

GPS

Navigation Notes:

Winches

Trawl Winch with 9/16th trawl wire

Winch Notes: We will bring a LEBUS mooring winch

Wire use and application

CTD Winch with .322" Electro-mechanical wire
Trawl Winch with 9/16th trawl wire


Wire Notes:

The trawl wire is necessary if we need to drag for any of the moorings.


Slip ring required? no Number of conductors:
Non-standard wire required? no Type:
Traction winch required? no Describe:

Other Science Vans:

Over the Side Equipment

Will you be bringing any equipment (winches, blocks, etc.) that lowers instruments over the side? yes

Details: We will bring a LEBUS winch and necessary blocks for the mooring work.

Special Requirements


Elecrical Power: no Identify:
Equipment Handling: yes Identify: Mooring Deployment
Inter/intraship Communications: no Identify:
Science Stowage: no Identify:
Water: no Identify:

Additional Cruise Items/Activities


Explosive Devices: no
Portable Air Compressors: no
Flammable Gases: no
 Small Boat Operations: no
SCUBA Diving Operations: no

Hazardous Material


Will hazardous material be utilized? yes

Radioactive Material

Radioiosotopes: no

Additional Information


Is night time work anticipated on this cruise? yes

Specialized tech support (Seabeam, coring, other):

SSSG Techs should be capable of running the acoustics for this cruise.



Other required equipment and special needs:




Date Submitted: Jun 6, 2020 4:25 PM
