Woods Hole Oceanographic Institution

Cruise Planning Questionnaire

OSNAP

Ship

RV Neil Armstrong

Vehicles


Cruise Party

Robert Pickart: Chief Scientist, Principal Investigator
Woods Hole Oceanographic Institution Clark 359B, MS#21 Woods Hole, Ma. USA 02543
+1 508 289 2858
rpickart@whoi.edu

Fiamma Straneo: Principal Investigator
Woods Hole Oceanographic Institution Clark 339, MS#21 Woods Hole, Ma. USA 02543
+1 508 289 2914
fstraneo@whoi.edu


Departure: Reykjavik, Iceland on Aug 27, 2018

Arrival: Reykjavik, Iceland on Oct 3, 2018

Supporting documentation:

»OSNAP_Straneo_As_deployed_2016.pdf
»OSNAP_Pickart_As_deployed_2016.pdf
»stations_tentative_ar30.txt

Operations Area: Southern Greenland; Denmark Strait


Lat/Lon: 59° 20.0′ N / 43° 50.0′ W

Depth Range: 100 / 3500

Will the vessel be operating within 200 NM of a foreign country? Canada, Greenland, Iceland
Are visas or special travel documents required? no

Science objectives

This research is part of the Overturning in the Subpolar North Atlantic Program (OSNAP), an effort to determine the strength of the meridional overturning circulation and associated heat and freshwater fluxes in the subpolar North Atlantic. It is a collaborative program with scientists from several nations, including the U.K., the Netherlands, Germany, France, Canada and China.

The specific objectives of this cruise are as follows:

1. To service 18 current meter and sound source moorings in the southeast Labrador Sea and southwest Irminger Sea.
2. To conduct a hydrographic/velocity survey in the vicinity of Cape Farewell and in Denmark Strait.


Science Activities

1. We will recover 18 moorings and deploy 17 moorings. There are three types of moorings: tall oceanographic moorings (9); shelf-tripods (8); sound source mooring (1).

2. We will occupy CTD/LADCP/Microstructure stations at all of the mooring sites, and also carry out a CTD/LADCP/Microstructure survey.

3. We will collect underway data throughout the cruise (vessel-mounted ADCP, Knudsen, met sensors).


Pre-cruise planning meeting: Visit WHOI

Stations:


Funding Agency: NSF #OCE-1259618


- added NSF #OCE-1259618 on May 25, 2018 4:09 PM by
<Could not load the preview of Funding data >

R/V Armstrong

Shipboard Equipment

Bathymetry System 12 kHz
ADCP 300 kHz
Sippican XBT System (Mark 21)
Bathymetry System 3.5 kHz
ADCP 150 kHz
A-Frame
Science Underway Seawater System
12 kHz Pinger for Wire Use
EM122 (12 kHz) Multibeam Echosounder
EK80 Sonar
Dynamic Positioning System
K-Synch System
Plotters
ADCP 38 kHz
Crane
EM710 MkII (40 to 100 kHz) Multibeam Echosounder


Shipboard Equipment Notes:

Shipboard Communication

Basic Internet access via HiSeasNet


Shipboard Communication Notes:

CTD/Water Sampling

Wet Labs ECO-AFL fluorometer
Wet Labs C*Star transmissometer (660nm wavelength)
Seapoint STM turbidity sensor
SBE43 oxygen sensor
911+ Rosette 24-position, 10-liter bottle Rosette with dual T/C sensors
Biospherical underwater PAR (1000m depth limit) with reference Surface PAR
Wet Labs FLNTURTD Combination Flourometer and Turbidity Sensor

Critical CTD Sensors:  We will attach 4 chipod sensors to the rosette. We need a complete backup CTD system.

CTD-Related Equipment

Lowered Acoustic Doppler Current Profiler (LADCP)

Hydrographic Analysis Equipment

Salinometer
Salt Bottles (2 cases of 125 ml provided)

MET Sensors

Barometric Pressure
Air temperature
Precipitation
Relative Humidity
Wind speed and direction
Short Wave Solar Radiation
Long Wave Solar Radiation


Storage Notes:

Navigation

GPS

Navigation Notes:


Winch Notes:

Wire use and application

CTD Winch with .322" Electro-mechanical wire
Trawl Winch with 9/16th trawl wire


Wire Notes:

The trawl wire is necessary if we need to drag for any of the moorings.


Slip ring required? no Number of conductors:
Non-standard wire required? no Type:
Traction winch required? no Describe:

Other Science Vans:

Over the Side Equipment

Will you be bringing any equipment (winches, blocks, etc.) that lowers instruments over the side? yes

Details: We will bring a TSE winch and necessary blocks for the mooring work.

Special Requirements


Elecrical Power: no Identify:
Equipment Handling: yes Identify: Mooring Deployment
Inter/intraship Communications: no Identify:
Science Stowage: no Identify:
Water: no Identify:

Additional Cruise Items/Activities


Explosive Devices: no
Portable Air Compressors: no
Flammable Gases: no
 Small Boat Operations: no
SCUBA Diving Operations: no

Hazardous Material


Will hazardous material be utilized? no

Radioactive Material

Radioiosotopes: no

Additional Information


Is night time work anticipated on this cruise? yes

Specialized tech support (Seabeam, coring, other):

SSSG Techs should be capable of running the acoustics for this cruise.



Other required equipment and special needs:



Date Submitted: May 25, 2018 4:35 PM
