| 1. Microscopes for study and photographing of samples.
|
| 2. Carbon coater for sample coating prior to insertion into 3F and 1280.
|
| 3. Gold coater for sample coating prior to insertion into 3F and 1280.
|
| 4. Exit slit of the IMS 1280.
|
| 5. Exit Slit with LP2C lens removed from Projection Chamber.
|
| 6. Visible inside Projection Chamber are LP2C, Exit ESA and Lens LD.
|
| 7. Lens LD focuses the beam for both the Faraday Cup and EM axial detector.
|
| 8. LP4C for final focusing before imaging on the Channel Plate.
|
| 9. Channel Plate for creating an image.
|
| 10. Projection Chamber with mono-collection. Visible are LD lens, Exit ESA, LP2C, Exit Slit, (LP2C removed) and Projection Gate.
|
| 11. Isolation Valve of the Projection Chamber.
|
| 12. Hexapole HP1 located next to Secondary Magnet and used for adjusting finely the tilt angle of secondary ion beam.
|
